Product Name :
Linear ActuatorApplication :
medical equipment, smart furniture, large livestock farms, solar tracking, military aerospace, industrial automation.Packing :
CartonNo-load Speed :
5mm/s 10mm/s 13mm/s 15mm/s 20mm/s 30mm/s 40mm/s 52mm/s 66mm/s 88mm/sThrust Force :
100/150/300/400/600/800/1200/2500 NStroke :
50-1000mmPull Force :
100/150/300/400/600/800/1200/2500 NSelf-locking Force :
100/200/400/600/800/1200/2500NInput Voltage :
12/24VProtection Grade :
IP43
| Certification： | ROHS CE |
| Input Voltage： | 12/24V |
| No-load Speed: | 5-110mm/s |
| Force: | 100-2500N |
| Stroke: | 20mm-1600mm or Customized |
| Work Temperature: | -20~80℃ |
| Operating frequency: | S2-10min |
| Loaded Curent: |
12V/4A 24V/3A |
| Limit switch: | built-in |
We specialize in the development and production of electric push rod, linear drive. Application of medical equipment, smart furniture, large livestock farms, solar tracking, military aerospace, industrial automation.
Linear actuator have been applied in many fields, with characteristics such as small size, high accuracy, complete synchronization, and good self-locking performance. They are often used in sports drives in industries such as household appliances, kitchenware, medical devices, and automobiles.
We specialize in the development and production of electric push rod, linear drive. Application of medical equipment, smart furniture, large livestock farms, solar tracking, military aerospace, industrial automation.
Linear Actuator belong to a new type of mechanism that can perform repetitive linear motion. The overall structure of electric push rods is simpler, and their size is smaller, thus reducing the overall size of the equipment. At the same time, it also has advantages such as price economy and strong adaptability, which are increasingly valued by people.
We specialize in the development and production of electric push rod, linear drive. Application of medical equipment, smart furniture, large livestock farms, solar tracking, military aerospace, industrial automation.
We specialize in the development and production of electric push rod, linear drive. Application of medical equipment, smart furniture, large livestock farms, solar tracking, military aerospace, industrial automation.
Linear actuator have a significant impact on the operational quality of the entire equipment. Therefore, in its production and design, it is not only necessary to strictly control the process standards, but also to develop reasonable performance parameters. At the same time, users should choose suitable electric push rod equipment based on their actual needs.
We specialize in the development and production of electric push rod, linear drive. Application of medical equipment, smart furniture, large livestock farms, solar tracking, military aerospace, industrial automation.
